The light guide rod is a type of glass fiber, which is formed by melting a bundle of regularly arranged multi-component glass fiber fine wires. It can be used for light transmission and low resolution image transmission. Its advantages are wide spectral range, light transmission, balanced output spot, and good temperature resistance; Mainly used as light guide components for dental curing machines and semiconductor lasers; The tail tapered condensing light guide rod can significantly improve the output illumination.
Product parameter
| Materials | Optical glass, quartz, infrared material |
| Contour Range | 0.5-500mm |
| Contour tolerance | 0/-0.02 |
| Angle Tolerance | 5 " |
| Surface Quality | 20-10 |
| Surface Flatness | N≤1, △N≤0.2 |
| Chamfer | ≤0.1 |
| Clear Aperture | > 90% |
| Coating | According to customer requirements |
